AIRCO A2 SERIES
MODELS 10, 20
THREAD PATTERN FRONT: 5/16" x 32
REAR: 1/4" x 28
CUP
ALUMINA
- A4A2 (2304-0069)
- A5A2 (2304-0070)
- A6A2 (2304-0073)
- A7A2 (2304-0074)
CERAMIC
- A4C3 (2304-0079C)
- A5C3 (2304-0080C)
- A6C3 (2304-0081C)
- A8C3 (2304-0082C)
- A10C3 (2304-0083C)
NOSE BLOCK
NOSE TRANSFER BLOCK
- ANT35 (2310-1938)
COLLET
- A20C20 (2304-0138)
- A40C20 (2304-0137)
- A116C20 (2304-0136)
- A332C20 (2304-0135)
- A418C20 (2304-0068)
HEATSHIELD
- AHS20
TORCHES USED ON:
- CKA10
- CKA20
| TUNGSTEN ELECTRODE CONVERSION CHART |
||
| SIZE SUFFIX | INCHES | MILLIMETERS |
| 20 | .020" | .5MM |
| 40 | .040" | 1.0MM |
| 116 | 1/16" | 1.6MM |
| 332 | 3/32" | 2.4MM |
| 418 | 1/8" | 3.2MM |
| 532 | 5/32" | 4.0MM |
| 316 | 3/16" | 4.8MM |
| 14 | 1/4" | 6.4MM |
A332C20 Size Code
AIRCO A3 SERIES
MODELS 16, 35
THREAD PATTERN FRONT: 3/8" x 32
REAR: 5/16" x 24
CUP
ALUMINA
- A4A3 (2304-0079)
- A5A3 (2304-0080)
- A6A3 (2304-0081)
- A8A3 (2304-0082)
- A10A3 (2304-0083)
CERAMIC
- A4C2 (2304-0002C)
- A5C2 (2304-0004C)
- A6C2 (2304-0049C)
NOSE BLOCK
NOSE TRANSFER BLOCK
- ANT20 (2310-1810)
COLLET
- A20C35 (2304-0086)
- A40C35 (2304-0087)
- A116C35 (2304-0088)
- A332C35 (2304-0089)
- A418C35 (2304-0090)
- A532C35 (2304-0091)
- A316C35 (2304-0146)
HEATSHIELD
- AHS35 (2310-2014)
TORCHES USED ON:
- CKA16
- CKA35
| TUNGSTEN ELECTRODE CONVERSION CHART |
||
| SIZE SUFFIX | INCHES | MILLIMETERS |
| 20 | .020" | .5MM |
| 40 | .040" | 1.0MM |
| 116 | 1/16" | 1.6MM |
| 332 | 3/32" | 2.4MM |
| 418 | 1/8" | 3.2MM |
| 532 | 5/32" | 4.0MM |
| 316 | 3/16" | 4.8MM |
| 14 | 1/4" | 6.4MM |
A332C35 Size Code
