STANDARD MACHINE SERIES

THREAD PATTERN FRONT: 3/8"x32
REAR: 5/16"x24



CUP

ALUMINA

  • 3A4 (10N50)
  • 3A5 (10N49)
  • 3A6 (10N48)
  • 3A7 (10N47)
  • 3A8 (10N46)
  • 3A10 (10N45)
  • 3A12 (10N44)

CERAMIC

  • 3C4 (105Z43)
  • 3C5 (105Z42)
  • 3C6 (105Z44)
  • 3C7 (105Z45)
  • 3C8 (08N78)
  • 3C10 (08N79)
  • 3C12 (08N80)

ALUMINA - GAS LENS

  • 3AG4 (54N18)
  • 3AG5 (54N17)
  • 3AG6 (54N16)
  • 3AG7 (54N15)
  • 3AG8 (54N14)
  • 3AG11 (54N19)
  • 3AG12

ALUMINA - LARGE DIAMETER

  • 3AG6LD (57N75)
  • 3AG8LD (57N74)
  • 3AG10LD (53N88)
  • 3AG11LD (53N89)
  • 3AG12LD (53N87)

COLLET BODY

STANDARD

  • 3CB20 (10N29)
  • 3CB40 (10N30)
  • 3CB116 (10N31)
  • 3CB332 (10N32)
  • 3CB418 (10N28)
  • 3CB532 (406488)

GAS LENS

  • 3GL20 (45V29)
  • 3GL40 (45V24)
  • 3GL116 (45V25)
  • 3GL332 (45V26)
  • 3GL418 (45V27)
  • 3GL532 (45V28)

LARGE DIAMETER

  • 3GL116LD (45V116)
  • 3GL332LD (45V64)
  • 3GL418LD (995795)
  • 3GL532LD (45V63)

COLLET

SHORT

  • 4C20 (10N21S)
  • 4C40 (10N22S)
  • 4C116 (10N23S)
  • 4C332 (10N24S)
  • 4C418 (10N25S)
  • 4C532

HEATSHIELD

STANDARD

  • M-HS

GAS LENS

  • M3G-HS

LARGE DIAMETER

  • M3G-HSLD

TROCH W/ACM

THREAD PATTERN FRONT

  • MT100
  • MT400
  • MT500
  • CWMT400
  • CWMT500

TUNGSTEN ELECTRODE
CONVERSION CHART
SIZE SUFFIX INCHES MILLIMETERS
20 .020" 0.5mm
40 .040" 1.0mm
116 .1/16" 1.6mm
332 .3/32" 2.4mm
418 .1/8" 3.2mm
532 .5/32" 4.0mm
316 .3/16" 4.8mm
14 .1/4" 6.4mm

4C332 Size Suffix
